Baicells – NOVA249
BaicellsThe Baicells Nova249 eNodeB (eNB) is a powerful outdoor radio, perfect for long-range deployments in rural and urban environments. Providing 2x40W of output power, this unit can blast through NLOS environments or provide long-range coverage. Connect distant subscribers with high-speed, reliable internet utilizing bands 3,5,8, or 28. This unit can be built for custom solutions, depending on your spectrum requirements.
-
Description
This Baicells Nova249 eNodeB (eNB) is an outdoor Long-Term Evolution (LTE) product that operates in Frequency Division Duplexing (FDD) mode. This eNB provides users with high-speed broadband wireless access to the Internet using 2*40W output power (2×2 MIMO with 40W output each channel). This unit is compact, lightweight, and easy to deploy. The Nova249 eNB offers excellent performance, helping operators to provide better coverage and higher capacity.
Specifications
| Item | NOVA249 |
| LTE Mode | FDD |
| Frequency Bands | 3/5/8/28 and customizable |
| Channel Bandwidth | Band3/28: 5/10/15/20 MHz | Band5/8: 5/10 MHz |
| MAX Output Power | 46 dBm / channel |
| MIMO | DL: 2×2 |
| Peak Rate | 20MHz: DL 150Mbps, UL 50Mbps | 10MHz: DL 75Mbps, UL 25Mbps |
| User Capacity | 256 concurrent users |
| Antenna | External high gain antenna compatible with eNB mini-DIN connectors |
| Synchronization | GPS |
| Dimensions | Band3: 16.9 x 10.8 x 4.4 inches 430 x 275 x 113 millimeters | Band5/8/28: 16.9 x 10.8 x 5.4 inches 430 x 275 x 137 millimeters |
| Weight | Band3: 26.5 lbs / 12kg | Band5/8/28: 33.1 lbs / 15kg |
| Backhaul |
